VMP Pressure Maintenance Valve

End of Arm Tooling

• Normally closed valve that can be used to maintain gripper pressure in case of overall pressure loss.
• Can be used in place of mechanical gripper mounted force maintenance options (versions MA/MC).
• Operating pressure: 2-10 bar.
• Operating temperature: -10° C to 80° C
• IP67 rating.
• In-out pressure drop of 0.5 bar.
• 15ms valve switching time.
• Weighs 0.1 kg.
• Flow rates: 6 mm tube – 200 L/min; 8 mm tube – 250 L/min; 10 mm tube – 340 L/min
