Valve Type: 24 VDC 3-Position 4-Port P-Blocked Center
2HP Low Pressure Advanced Workholding Pump: PALLET DECOUPLER TWO HOSE S/A OR D/A
- Double or single acting systems.
- Use 1 or 2 handed auto-shutoff pallet decoupler.
- P-blocked center valve drops pressure in both lines.
- Allows decoupling and re-coupling of the hoses.
- Operator interface is remote pendant or wired into a machine controller.
Efficient ON DEMAND pump with NO DUTY CYCLE
Vektek’s NEW LOW PRESSURE Advanced Workholding Pump is an efficient ON DEMAND pump with NO DUTY CYCLE limitations due to it’s Variable Frequency Drive (VFD). Once pressure is met, the pump turns off while holding pressure, if a pressure decay occurs the on-demand pump will re-start and build pressure to the correct pressure setting.
This gear pump’s flow rate pushes 250 cu. in. of oil up to 1500 PSI all in a single stage. For your Low Pressure Applications you can count on Vektek’s NEW Low Pressure Advanced Workholding Pumps.
Pump Add-on Options
- Valve Wiring Cable (one for each valve).
- Pump/Machine Tool Interface Cable (all pump control in one cable).
- Upgrade to fluid level temperature switch.
- Upgrade to Electronic clog indicator return line filter.
- Mechanical pressure switch (no power required).
- Electronic pressure switch (24V power required).
- Manual or solenoid directional control valve functions.
- Check Valve (for multiple manual valves in stack).
- Pressure reducing valves for each circuit.
- Accumulator (for small or low pressure systems).
- Extra pendant switches (1 supplied with each different solenoid valve on pump for setup and testing).
- Return Line Water Absorbing Filter with models available for use without cart and with cart.
Valve Wiring Cable, M12, 5 pin (add one cable per valve)
- Allows for a single valve to be wired and controlled from the machine.
- Plugs in place of a pendant but doesn’t provide pump sensor feedback.
- Cost effective and simple to integrate solution for machine control of each valve.
Pump/Machine Tool Interface Cable, 24 pin or 36 pin, Single Connection (*Contact your sales representative for details.)
- Allow up to 1-4 or 5-6 valves to be controlled from machine.
- Each valve can use a clamp and unclamp pressure switch.
- Provides pump sensor feedback for diagnosis of fault.
- Emergency stop input can be used to stop pump from machine.
- Fully integrated to pump control, requires connection to customer machine.
| Model No. | Valve Type | Electrical Voltage | No Of Valves |
|---|---|---|---|
| 55-7675-27-1 | 24 VDC 3 Position 4 Port P-Blocked Center | 200 - 240 VAC 3 Phase | 1 |
| 55-7675-27-2 | 24 VDC 3 Position 4 Port P-Blocked Center | 200 - 240 VAC 3 Phase | 2 |
| 55-7675-27-4 | 24 VDC 3 Position 4 Port P-Blocked Center | 200 - 240 VAC 3 Phase | 4 |
| Model No. | Valve Type | Electrical Voltage | No Of Valves |
|---|---|---|---|
| 55-7695-27-1 | 24 VDC 3 Position 4 Port P-Blocked Center | 380 - 500 VAC 3 Phase | 1 |
| 55-7695-27-2 | 24 VDC 3 Position 4 Port P-Blocked Center | 380 - 500 VAC 3 Phase | 2 |
| 55-7695-27-4 | 24 VDC 3 Position 4 Port P-Blocked Center | 380 - 500 VAC 3 Phase | 4 |
| Model No. | Pump Flow - Stage 1 | Pressure Range - Stage 1 | Reservoir Capacity | Viscosity (cSt) |
|---|---|---|---|---|
| 55-7675-27-1 | 250 cu. in. | 0 - 1500 psi | Gross - 5.0 gal / Useable - 3.5 gal | 22 - 46 @ 40° C |
| 55-7675-27-2 | 250 cu. in. | 0 - 1500 psi | Gross - 5.0 gal / Useable - 3.5 gal | 22 - 46 @ 40° C |
| 55-7675-27-4 | 250 cu. in. | 0 - 1500 psi | Gross - 5.0 gal / Useable - 3.5 gal | 22 - 46 @ 40° C |
| Model No. | Pump Flow - Stage 1 | Pressure Range - Stage 1 | Reservoir Capacity | Viscosity (cSt) |
|---|---|---|---|---|
| 55-7695-27-1 | 250 cu. in. | 0 - 1500 psi | Gross - 5.0 gal / Useable - 3.5 gal | 22 - 46 @ 40° C |
| 55-7695-27-2 | 250 cu. in. | 0 - 1500 psi | Gross - 5.0 gal / Useable - 3.5 gal | 22 - 46 @ 40° C |
| 55-7695-27-4 | 250 cu. in. | 0 - 1500 psi | Gross - 5.0 gal / Useable - 3.5 gal | 22 - 46 @ 40° C |
| Model No. | Description |
|---|---|
| 95-5954-50 | CABLE, VALVE WIRING,1 VLV, M12, 5 PIN, 16.4 FT |
| Model No. | Description |
|---|---|
| 27-7422-03 | CABLE,M12 MALE,M12 FEMALE,5 POLE,16.4 FT |
| 27-9422-02 | CABLE,M12 MALE,M12 FEMALE,5 POLE, 32.8 FT |
| 95-5955-37 | PENDANT SWITCH, 2/3 VALVE, 6 FT, NORMALLY OPEN, (ON/OFF) |
| 95-5955-38 | PENDANT SWITCH, 2/3 VALVE, 6 FT, NORMALLY CLOSED, (OFF/ON) |
| 95-5955-39 | PENDANT SWITCH, 2/3 VALVE, 6 FT, NORMALLY CLOSED, (OFF/MOMENTARY ON) |
| 95-5955-40 | PENDANT SWITCH, 3/4 VALVE, 6 FT, CLOSED CENTER OR P-BLOCK CENTER, (ON/OFF/ON) |
| Model No. | Description |
|---|---|
| 31-0500-18 | FILTER, CARTRIDGE, AWP, 10 MICRON |
| 31-0500-26 | FILTER, SPIN-ON, 10 µm, WATER ABS |
| 62-5595-07 | FILTER, WATER ABSORBING, 10 µm |
| 62-5595-08 | FILTER, WATER ABSORBING, 10 µm, CART |
